Sludge Ash Pump

Modo Pump has been focused on sludge ash pump manufacturing and selling for many years, which is known as a professional manufacturer and supplier of various quality pumps in China. We have gathered many professional and experienced staff, as well as advanced equipment in our factory. Welcome to buy our sludge ash pump and check the price list with us.



Sludge Ash Pump have been making waves in the mining industry due to their outstanding resistance to wear and corrosion. pumps are designed to handle abrasive slurry with minimum wear and tear, ensuring long-lasting service. The use of rubber in the lining material significantly enhances the pump's resistance to corrosion, thereby reducing maintenance costs and increasing overall efficiency.

Sludge Ash Pump that can handle a wide range of slurry types while providing reliable and efficient performance. Traditional pumps have a high probability of experiencing erosion and corrosion, leading to frequent breakdowns and repairs. However, the introduction of rubber lined anti-corrosive slurry pumps has revolutionized this aspect of the industry.

Sludge Ash Pump have many benefits, including reduced downtime, increased productivity, and lower operational costs. They are available in various sizes and configurations, making them ideal for diverse mining applications. The use of Sludge Ash Pump has significantly reduced the need for frequent maintenance, allowing for continuous operation and increased production.

Available Models Of Sludge Ash Pump

Type	Max. power	Capacity	Head	Speed	Max.Eff	NPSH	Impeller Dia.	Max.particle size
	(kw)	(m³/h)	(m)	(r/min)	(%)	(m)	(mm)	(mm)
MAH1.5-1	15	12-28	6-65	1200-3800	40	2-4	150	14
MAH2-1.5	15	32-72	6-58	1200-3200	45	3.5-8	185	19
MAH3-2	30	39-86	12-64	1300-2700	55	4-6	215	25
MAH4-3	60	86-198	9-52	1000-2200	71	4-5	245	28
MAH6-4	120	162-360	12-56	800-1500	68	5-8	365	44
MAH8-6	120	360-830	10-61	500-1140	72	2-9	510	63
MAH10-8	260	612-1368	11-61	400-850	71	4-10	685	76
MAH12-10	560	936-1980	7-68	400-750	82	1-5	760	86
MAH14-12	560	1260-2772	13-63	300-600	77	3-10	965	90

Exploded diagram of Sludge Ash Pump

Spare parts of Sludge Ash Pump:

Rubber Pumps Material			Metal Pumps Material
No	Part	Material	No	Part	Material
1	Base	Cast Iron	1	Base	Cast Iron
2	Shaft	4140 High Tensile Steel*	2	Shaft	4140 High Tensile Steel*
3	Bearing Assembly	Timken (Cast Iron Body)	3	Bearing Assembly	Timken (Cast Iron Body)
4	Shaft Sleeve	420 Stainless Steel	4	Shaft Sleeve	420 Stainless Steel
5	Pump Casing	Cast Iron	5	Pump Casing	Cast Iron
6	Frame Plate Liner Insert	Rubber	6	Frame Plate Liner	27% Chrome White Iron
7	Cover Plate Liner	Rubber	7	Volute Liner	27% Chrome White Iron
8	Impeller	Rubber Coated High Tensile Steel	8	Impeller	27% Chrome White Iron
9	Throat Bush	Rubber	9	Throat Bush	27% Chrome White Iron
10	Cover Plate	Cast Iron	10	Joint Rings	Rubber
11	Stuffing Box	Cast Iron	11	Cover Plate	Cast Iron
12	Expeller	27% Chrome White Iron	12	Stuffing Box	Cast Iron
13	Expeller Ring	Natural Rubber	13	Expeller	27% Chrome White Iron
14	Bolts	Zinc Plated Steel	14	Expeller Ring	Natural Rubber
15	O-rings	Nitrile Rubber	15	Bolts	Zinc Plated Steel
16	Seals	Rubber	16	O-rings	Nitrile Rubber
17	Seals	Rubber	17	Seals	Rubber

Sludge ash pumps are essential for a variety of industries that deal with the handling and disposal of hazardous waste materials.

Here are some of the advantages of using these pumps:

1. Efficient Handling: Sludge ash pumps are designed to handle high viscosity materials like sludge, ash and other waste products. They provide efficient and effective transfer of these materials for easy disposal, reducing the time and effort required for manual handling.

2. High Performance: These pumps are built to withstand harsh and demanding conditions, with a powerful motor and robust construction. They are capable of handling large volumes of waste materials, minimizing the need for multiple trips and boosting productivity.

3. Versatile: Sludge ash pumps are versatile and can be used for a wide range of applications. They can transfer liquid, semi-liquid and solid materials with ease and are applicable in wastewater treatment plants, power plants and chemical processing industries.

4. Low Maintenance: Quality sludge ash pumps require very little maintenance, ensuring that they are always available for use when needed and prolonging their lifespan.

5. Environmentally Friendly: Proper waste disposal is crucial for protecting the environment and ensuring public health. Sludge ash pumps are designed to effectively transfer hazardous waste materials without harming the environment, minimizing the risk of contamination and improving safety in the workplace.

Contact us for your solution!
