2 Inch Rubber Lined Horizontal Slurry Pump
The MAH series 12inch heavy duty horizontal slurry pump is designed for the continuous pumping of highly abrasive, high density slurries with minimal maintenance requirements. The MAH series slurry pump will maintain high efficiencies over the wear life of its components.
2 inch Rubber lined horizontal slurry pump
The MAH series 2 inch Rubber lined horizontal slurry pump is designed for the continuous pumping of highly abrasive, high density slurries with minimal maintenance requirements. The MAH series slurry pump will maintain high efficiencies over the wear life of its components.
2 Inch Rubber Lined Horizontal Slurry Pump Performance:
Type | Max. power | Capacity | Head | Speed | Max. Eff. | NPSH | Impeller Dia. | Max. Particle size |
kw | m³/h | m | r/min | % | m | mm | mm | |
MAH1.5-1 | 15 | 12-28 | 6-65 | 1200-3800 | 40 | 2-4 | 150 | 14 |
MAH2-1.5 | 15 | 32-72 | 6-58 | 1200-3200 | 45 | 3.5-8 | 185 | 19 |
MAH3-2 | 30 | 39-86 | 12-64 | 1300-2700 | 55 | 4-6 | 215 | 25 |
2 Inch Rubber Lined Horizontal Slurry Pump Features:
Material--The wet parts material for standard MAH series pump is high-chrome alloy. This kind of material is wear resistant and has excellent performance under erosive conditions.
Shaft Seal--There are three standard shaft seal methods: Packing seal, Expeller seal, Mechanical seal.
Bearing Assembly--Convenient to adjust the space between impeller and front liner and can be removed completely.
2 Inch Rubber Lined Horizontal Slurry Pump Pump Material:
Rubber Pumps Material | ||
No | Part | Material |
1 | Base | Cast Iron |
2 | Shaft | 4140 High Tensile Steel* |
3 | Shaft Sleeve | 420 Stainless Steel |
4 | Pump Casing | Cast Iron |
5 | Frame Plate Liner Insert | Rubber |
6 | Cover Plate Liner | Rubber |
7 | Impeller | Rubber Coated High Tensile Steel |
8 | Throat Bush | Rubber |
9 | Cover Plate | Cast Iron |
10 | Stuffing Box | Cast Iron |
11 | Expeller | 27% Chrome White Iron |
12 | Expeller Ring | Natural Rubber |
13 | Bolts | Zinc Plated Steel |
14 | O-rings | Nitrile Rubber |
15 | Seals | Rubber |
16 | Seals | Rubber |
Applications:
• Chemical Process
• Heavy Minerals
• Paper and Pulp
• Mill Discharge
• Processing Sugar Beet
