Split Casing Fire Fighting Pump

Modo Pump has been focused on split casing fire fighting pump manufacturing and selling for many years, which is known as a professional manufacturer and supplier of various quality pumps in China. We have gathered many professional and experienced staff, as well as advanced equipment in our factory. Welcome to buy our split casing fire fighting pump and check the price list with us.



Split Casing Fire Fighting Pump

Working Conditions:

The maximum working pressure of Split Casing Fire Fighting Pump volute double-suction pump system is 2.5Mpa, namely pump inlet pressure +pump lift head≤ 2.5Mpa, and the test pressure of pump static pressure is 3.75Mpa. According to the maximum pressure that the pump body can bear, the materials for body and bonnet adopt the grey cast iron(1.6Mpa), spheroidal graphite cast iron(2.0Mpa)and cast steel (2.5Mpa).  This series of pump can transport the clear water or other liquids with similar physical and chemical properties as clear water with temperture T≤ 105 deg C.

Split Casing Fire Fighting Pump Type Designation:

MS 300 - 450(I)A

300 - diameter of pump outlet (mm)
450 - nominal diameter of impeller (mm)
I - Flow classification
A - rimary cutting of impeller
