Stainless Steel Self-priming Pump

Stainless Steel Self-priming Pump

The stainless steel selfpriming pump is reliable in sealing. It adopts non leakage Bai sealing Du device, which is composed of dynamic seal and auxiliary seal. It replaces the packing seal and mechanical seal of the traditional water pump, and thoroughly solves the problems of "running, emitting, dripping and leaking" of the traditional seal. It is the most ideal product to replace the original long shaft submerged pump, submersible pump and submersible sewage pump.

2. The stainless steel selfpriming pump is made by MODO PUMP, which is a leader in the industry.

The stainless steel selfpriming pump is reliable in sealing. It adopts non leakage Bai sealing Du device, which is composed of dynamic seal and auxiliary seal. It replaces the packing seal and mechanical seal of the traditional water pump, and thoroughly solves the problems of "running, emitting, dripping and leaking" of the traditional seal. It is the most ideal product to replace the original long shaft submerged pump, submersible pump and submersible sewage pump

T series self-priming pumps are designed for economical & trouble-free operation in handling solids-laden liquids and slurries.


T Series pumps are designed for economical & trouble-free operation in handling solids-laden liquids and slurries. Pumps feature a large volute design which allows them to re-prime automatically in a completely open system without the need of suction or discharge check valves. And this is workable with the pump only partially filled with liquid and completely dry suction line.

Pumps will be able to handle up to 75mm spherical solids, depending on pump models. In case that pump shaft or bearings need service or repair, the entire rotating assembly can be removed without disturbing pump casing or pipelines.
Rotating assembly is sealed with an O-Ring, allowing for external adjustments of clearance.

Material: Cast Iron, CD4MCU, 316 SS


Data Sheet:


Type: T-2

Inlet, outlet: 2"

Max. Throught solids: 44.45mm

Head: 5m ~ 36m

Flow: 10m³ /h ~40m³ /h

Speed: 1150rpm ~2900rpm

Repriming lifts: 7.3m ~7.6m


Type: T-3

Inlet, outlet: 3"

Max. Throught solids: 63.5mm

Head: 4m ~ 35m

Flow: 10m³ /h ~100m³ /h

Speed: 650rpm~ 2150rpm

Repriming lifts: 1.5m~ 7.6m


Type: T-4

Inlet, outlet: 4"

Max. Throught solids: 76.2mm

Head: 4m ~ 35m

Flow: 20m³ /h ~150m³ /h

Speed: 650rpm~ 1950rpm

Repriming lifts: 1.5m~ 7.6m
