Axial Flow Pumps

Modo Pump has been focused on axial flow pumps manufacturing and selling for many years, which is known as a professional manufacturer and supplier of various quality pumps in China. We have gathered many professional and experienced staff, as well as advanced equipment in our factory. Welcome to buy our axial flow pumps and check the price list with us.



Axial flow pumps are device that uses the centrifugal force generated by the rotation of the impeller to transport liquid in an axial flow manner. It mainly consists of a pump casing, an impeller, inlet and outlet pipes and a motor. When the motor is started, the impeller starts to rotate, and the liquid enters the pump casing from the inlet pipe and is then pushed in the axial direction by the centrifugal force of the impeller. During the rotation of the impeller, the kinetic energy of the liquid gradually increases, and the pressure inside the pump casing also gradually increases. When the liquid reaches a certain pressure through the force of the impeller, it is discharged from the outlet pipe of the pump casing.

The structure of the axial flow pump mainly consists of the following parts:

Impeller: The function of the impeller is the same as that of a centrifugal pump, converting the mechanical energy of the prime mover into the pressure energy and kinetic energy of the fluid. It consists of blades, a hub and a moving blade adjustment mechanism. The blades are mostly airfoil-shaped, usually 4 to 6 blades.
Pump shaft: For axial flow pumps with large capacity and adjustable blades, the shafts are made of high-quality carbon steel and are hollow, with chrome plating on the surface, which can not only reduce the weight of the shaft, but also facilitate the installation of the adjustment mechanism.

Guide vanes: The guide vanes of these pumps are generally installed on the outlet side of the impeller. The function of the guide vanes is to convert the rotational motion of the water flow out of the impeller into axial motion, and at the same time convert part of the kinetic energy into pressure energy.

Suction pipe: The function of the suction pipe is the same as that of the suction chamber of the centrifugal pump. Small and medium-sized axial flow pumps mostly use trumpet-shaped suction pipes, and large axial flow pumps mostly use elbow-shaped suction channels.

The working principle of axial flow pumps is simple and efficient, and they are widely used in liquid transportation tasks in various fields.

Modo Pump Axial Flow Pump Features

Our axial flow pumps are designed with advanced technology to improve efficiency, reliability and service life. Here are the key features that make our pumps stand out in the market:

1. High Efficiency
- Axial flow pumps are designed for high flow rates and are extremely efficient. The axial design helps to simplify water flow, reduce energy consumption and improve overall operating efficiency.

2. Corrosion Resistant Materials
- Our pumps are made of high-quality corrosion-resistant materials such as stainless steel and cast iron, which can extend the life of the pump even when used in harsh environments. The casting materials of axial flow pumps make them durable and resistant to rust and corrosion, ensuring reliable performance in both freshwater and saltwater applications.

3. Wide Range of Sizes and Capacities
- We are able to provide axial flow pumps in a wide range of sizes, from small models for residential or light industrial use to large models capable of operating in large industries or irrigated agriculture. Our pumps can be customized to specific flow rates and pressures to meet all of your special needs.

4.Low Maintenance Costs
- Axial flow pumps are designed for easy maintenance, and durable components minimize wear and tear. Its simple design and rugged construction allow for fast and efficient routine maintenance, reducing downtime.

5.Customization
- We can provide customized solutions based on your needs. Whether you require a specific power, size, head or flow, our technical team can provide a tailor-made solution to meet your needs.

Modo Pump Axial Flow Water Pump Applications

Axial flow pumps are a versatile pump type that can be used in a variety of industries and environments. These pumps are used in a variety of applications including:

1. Agricultural irrigation systems

Water is vital in agriculture. Our axial flow pumps are widely used in irrigation systems, especially for large-scale extraction and transportation of irrigation water, and are an important tool for irrigating farmland. Our pumps have large flow rates and high energy efficiency, making them a reliable partner for modern agricultural operations.

2. Flood control and drainage systems

Axial flow pumps are the first choice for flood control and drainage applications, especially in areas with heavy rainfall or with the risk of waterfalls or floods. Our pumps can effectively transport large amounts of water from low-lying areas to high-lying areas and drainage systems, preventing flooding and minimizing flooding in urban and rural areas. Axial flow pump can transport large amounts of water at low pressures, which is essential for flood control and drainage operations.

3. Industrial water treatment

Axial flow pumps are commonly used in applications such as liquid transportation, circulating cooling, etc. in industries such as petroleum, chemical, steel, and power. Modo pump's axial flow pump can effectively treat water in industrial facilities that require high flow rates but not high pressures. Whether delivering water to cooling towers or cleaning wastewater from sewage treatment plants, our pumps can handle harsh industrial environments.

4. Urban water supply
- Axial flow pumps are also used in urban drainage systems. These pumps are commonly used in facilities such as urban sewage treatment plants, stormwater pumping stations and drainage mains. Our pumps have high conveying capacity and adaptability, allowing them to maintain excellent operating efficiency when handling large amounts of wastewater, making them an important part of urban drainage systems.

5. Marine and coastal applications
- Axial flow pumps are often used in shipbuilding and marine engineering. Due to their efficient flow transmission capacity and corrosion resistance, our pumps have become indispensable marine equipment, especially in water pump systems on ships and seawater booster systems on offshore platforms.

6. Environmental protection field
- As environmental protection requirements become more and more stringent, the use of axial flow pumps in sewage treatment, wastewater and other fields is increasing. The pumps are particularly suitable for large-volume wastewater delivery and liquid flow control in sewage treatment equipment, which can effectively improve the treatment efficiency of sewage treatment plants.

7. Mining and Construction
- Mining and construction projects in remote areas often require large amounts of water for drainage, excavation and other processes. The pumps are the right solution for pumping water in mines and construction sites, ensuring smooth and continuous operation.

Benefits of Modo Pump Axial Flow Water Pumps

1. High Flow
- One of the main benefits of axial flow pumps is their ability to deliver large volumes of water with minimal pressure requirements. This makes them ideal for areas that require large volumes of water but do not require high discharge pressures.

2. Energy Efficiency
- Modo Pump's axial flow pump is designed to be energy efficient, helping to reduce costs. The axial flow design reduces energy consumption compared to other types of pumps, especially when dealing with high-flow, low-pressure applications.

3. Cost-Effective
- Given their high efficiency and low maintenance requirements, Modo Pump's axial flow pump offer a cost-effective measure for long-term water supply. By reducing energy consumption and minimizing the need for frequent repairs or replacements, these pumps are more efficient over their service life.

4. Environmentally Friendly
- By consuming less energy and reducing operating costs, axial flow pump is a more sustainable, environmentally friendly choice for water management systems. Their efficiency helps minimize your carbon footprint.

5. Durability and Long Life
- Modo Pump's axial flow water pumps are made from high-quality materials that are resistant to corrosion and wear, ensuring a long service life even in harsh environments.

6. Reduced risk of clogging
- Axial flow water pumps are designed to minimize the risk of clogging compared to other types of pumps. The open impeller design and smooth water flow allow the pump to effectively handle solids and debris without clogging, ensuring continuous operation with minimal downtime.

7. Suitable for a wide range of applications
- Whether it is agricultural, industrial, municipal water supply or marine applications, our axial flow pumps can provide suitable solutions to meet the specific needs of different industries

600ZLB(ZLDB)-70 CHARACTERISTIC CURVES

600ZLB(ZLDB)-70CHARACTERISTIC DATA

Mounting Map of 600ZLB-70,600ZLB-100,600ZLB-160 Type Axial Pump

1.Pump base loads 7358N
2.The floor loads 20111N (no including motor weight)
3.L=2000-4500,to equip medium bearing as L>3100mm (Look like the map of 20ZLB-70)
